FTTH patch cord optical
subscriber outdoor 1SM
subscriber outdoor 1SM
Patch cords are used in the construction of communication networks and provide a higher installation speed and lower cost than using the conventional technology with fiber welding.
The patch cord is designed to be suspended on the poles when connecting subscribers.
The patch cord is designed to be suspended on the poles when connecting subscribers.
FTTH reinforced patch cord (FRP 1.8mm) 1SM
The FTTH trunk patch cord is designed for suspension on the poles of high-voltage lines during the construction of the trunk lines, as well as for connecting subscribers.
Patch cords are made according to individual customer projects.
Optical patch cord is made of outdoor cable.
The black shell is resistant to temperature changes.
Patch cords are made according to individual customer projects.
Optical patch cord is made of outdoor cable.
The black shell is resistant to temperature changes.
FTTH patch cord subscriber indoor
The patch cord is designed for indoor connection.
Patch cords are made according to individual customer projects.
Description: Optical patch cord is made of indoor cable.
The white shell is resistant to temperature changes.
Patch cords are made according to individual customer projects.
Description: Optical patch cord is made of indoor cable.
The white shell is resistant to temperature changes.
Вернуться назад
Optical distribution box UFN-FTTH-SPLIT
Specifications:
Overall dimensions: 330*270*110mm
Material – plastic
Number of inputs for a linear cable up to d14mm – 3 pieces
Number of inputs for the subscriber FTTH cable – up to 24 pieces
Cassette capacity up to 48 fiber fusion splices
Installation up to 2 PLC splitters
Installation up to 2 FBT splitters in mini-case
Advantages:
Opening of the box is not required for installation - the fasteners are located outside the body. No key is required to close the box. UV resistant. The ability to use the box in a wide range of low and high temperatures. Convenient installation and maintenance.
Complete set:
Plate for SC/LC Duplex adapters. Plate for the installation of two optical cassette splitters. Place for the installation of two optical fiber couplers enclosed. Place for installation of kits to protect the welding unit up to 48 pieces. Place for optical fibers and cords. Place for FTTH cable stock. Place of insertion and fixation of FTTH cables up to 24 pieces. The place of insertion and fixation of the trunk optical cables up to 3 pieces.
Overall dimensions: 330*270*110mm
Material – plastic
Number of inputs for a linear cable up to d14mm – 3 pieces
Number of inputs for the subscriber FTTH cable – up to 24 pieces
Cassette capacity up to 48 fiber fusion splices
Installation up to 2 PLC splitters
Installation up to 2 FBT splitters in mini-case
Advantages:
Opening of the box is not required for installation - the fasteners are located outside the body. No key is required to close the box. UV resistant. The ability to use the box in a wide range of low and high temperatures. Convenient installation and maintenance.
Complete set:
Plate for SC/LC Duplex adapters. Plate for the installation of two optical cassette splitters. Place for the installation of two optical fiber couplers enclosed. Place for installation of kits to protect the welding unit up to 48 pieces. Place for optical fibers and cords. Place for FTTH cable stock. Place of insertion and fixation of FTTH cables up to 24 pieces. The place of insertion and fixation of the trunk optical cables up to 3 pieces.
Camel-3 PON distribution box
It is used in the construction of PON on the poles.
Overall dimensions: 390X450X170 Box has 4 slots for placement of: removable panel for optical distribution frames or optical cassette splitter (130x100x25 mm) Parameters: number of trunk fiber optics d10 mm – up to 4 pcs., number of subscriber fiber optics d6 mm – up to 16 pcs.
Installation: the box is mounted o the pole using 2 mounting tapes Material: galvanized steel sheet with subsequent powder coating.
Overall dimensions: 390X450X170 Box has 4 slots for placement of: removable panel for optical distribution frames or optical cassette splitter (130x100x25 mm) Parameters: number of trunk fiber optics d10 mm – up to 4 pcs., number of subscriber fiber optics d6 mm – up to 16 pcs.
Installation: the box is mounted o the pole using 2 mounting tapes Material: galvanized steel sheet with subsequent powder coating.
Sharpei-TO Subscriber Optical Box
For installation in hallways, stair halls. It is used in the construction of PON in apartment buildings. Cable stocks up to 30 cm - max 8 pcs.
To close/open the box use an eccentric service key (not included in the set). Welding of the fiber optic cable is not applicable.
Related Products: 1.
Eccentric service key 2.
Semi-circular metal duct d14mm 3.
Semi-circular metal duct d22mm
To close/open the box use an eccentric service key (not included in the set). Welding of the fiber optic cable is not applicable.
Related Products: 1.
Eccentric service key 2.
Semi-circular metal duct d14mm 3.
Semi-circular metal duct d22mm
GNOM-2 Subscriber optical box
Designed for installation in existing hallway low-current cabinets / trunks, as well as on the hallway wall.
It is used in the construction of PON in apartment buildings.
This box can be used in conjunction with a semi-circular metal duct d22 mm. Welding of the fiber optic cable is not applicable.
Related Products: 1.
Eccentric service key 2.
It is used in the construction of PON in apartment buildings.
This box can be used in conjunction with a semi-circular metal duct d22 mm. Welding of the fiber optic cable is not applicable.
Related Products: 1.
Eccentric service key 2.
Video camera box with a support
It is intended for installation of video cameras on poles.
Complete set: • box – 1 pc.• gasket d20 mm – 1 pc.
Installation: the box is mounted to the pole by means of a mounting tape, the video camera is installed directly in the box by means of self-tapping screws (not included in the set).
The set includes a box for disconnecting FTP and standard camera wires, as well as a support to attach the incoming cable.
Complete set: • box – 1 pc.• gasket d20 mm – 1 pc.
Installation: the box is mounted to the pole by means of a mounting tape, the video camera is installed directly in the box by means of self-tapping screws (not included in the set).
The set includes a box for disconnecting FTP and standard camera wires, as well as a support to attach the incoming cable.
DRS box type 12
For installation in hallways, stair halls:
- access level switches up to 3 pcs;
- optical node;
- house amplifier of any type except SD1200, or SD1200 amplifier without optical node;
- 600x890 box grid for installation of media converters or subscriber TV couplers; optical cassette 1 pc or optical distribution frame 8/16 ports;
- uninterruptible power supply, if the optical node and the house amplifier are not installed;
- plate (for cassette) PKU 1/19";
- it is equipped with a plate with a hook for suspension of the amplifier SD1200 or optical node
Spinner 9U box
It is used to place station equipment, its power supply and power redundancy in one cabinet. The power supply equipment is located at the bottom of the box, including batteries.
Complete set:
• box
• Lock with three-way crossbars with a set of keys
The box can be completed on request with:
• foiled isolon
• electrical equipment
• heater
• fans
• access control system
The box can be placed:
Both indoors and outside buildings as a thermal cabinet when insulated with foiled isolon, with the installation of a heater and fans.
Ventilation openings require the installation of vent screens.
Complete set:
• box
• Lock with three-way crossbars with a set of keys
The box can be completed on request with:
• foiled isolon
• electrical equipment
• heater
• fans
• access control system
The box can be placed:
Both indoors and outside buildings as a thermal cabinet when insulated with foiled isolon, with the installation of a heater and fans.
Ventilation openings require the installation of vent screens.
Ventilation openings require the installation of vent screens.
Designed to allocate a telecommunications rack with communication equipment.
Complete set:
• container
• protective cover of the external air conditioner unit
• lock with a set of keys
The container can be completed on request with:
• electrical installation components
• air conditioning
• security and fire alarm systems
• electric heater
• access control system. The container has a place for:
• 42U telecommunications rack, 19", 800 mm
• air conditioning with capacity up to 2.6 kW
• wall heater
Complete set:
• container
• protective cover of the external air conditioner unit
• lock with a set of keys
The container can be completed on request with:
• electrical installation components
• air conditioning
• security and fire alarm systems
• electric heater
• access control system. The container has a place for:
• 42U telecommunications rack, 19", 800 mm
• air conditioning with capacity up to 2.6 kW
• wall heater
Вернутся назад
Fastening unit UK-N light
It is used in the construction of trunk line and subscriber fiber optic network as an anchor and/or supporting fastening.
Working load in tension mode is 2 kN
Working load in operation mode is 0.5 kN
Installation:
The unit is attached to the pole with a mounting tape (2 pcs.)
Overall dimensions:
Width 70 mm
Height 50 mm
Material:
angle steel 40*40*2 steel wire (d6 mm).
Working load in tension mode is 2 kN
Working load in operation mode is 0.5 kN
Installation:
The unit is attached to the pole with a mounting tape (2 pcs.)
Overall dimensions:
Width 70 mm
Height 50 mm
Material:
angle steel 40*40*2 steel wire (d6 mm).
Fastening unit UK-N/P
It is used in the construction of trunk line and subscriber fiber optic network as an anchor and/or supporting fastening.
Working load in tension mode is 2 kN
Working load in operation mode is 0.5 kN
Installation:
The unit is attached to the pole with a mounting tape (2 pcs.)
(Not included).
Overall dimensions:
Width 150 mm
Height 185 mm
Material:
angle steel 40*40*2 steel wire (d6 mm).
Working load in tension mode is 2 kN
Working load in operation mode is 0.5 kN
Installation:
The unit is attached to the pole with a mounting tape (2 pcs.)
(Not included).
Overall dimensions:
Width 150 mm
Height 185 mm
Material:
angle steel 40*40*2 steel wire (d6 mm).
Universal fastening unit UK-N/U
It is used as an anchor fastening of trunk and subscriber networks, provides the offset of the anchorage point of the fiber optic cable from the pole at a distance of 150 mm.
This fastening unit can be fitted with a Optical box support with 150 mm offset (on SV poles) to install the optical box.
Installation:
The unit is mounted with a mounting tape (1 piece).
Working load in tension mode is 2 kN. Working load in operation mode is limited by the strength of the mounting tape (0.5 kN with 0.7*19 AISI 201 tape).
Overall dimensions:
Total length 526 mm Offset 150 mm
Width 40 mm
Material: angle steel 40*40*2 steel wire (d6 mm).
This fastening unit can be fitted with a Optical box support with 150 mm offset (on SV poles) to install the optical box.
Installation:
The unit is mounted with a mounting tape (1 piece).
Working load in tension mode is 2 kN. Working load in operation mode is limited by the strength of the mounting tape (0.5 kN with 0.7*19 AISI 201 tape).
Overall dimensions:
Total length 526 mm Offset 150 mm
Width 40 mm
Material: angle steel 40*40*2 steel wire (d6 mm).
Optical box support
It is used in the construction of trunk and subscriber fiber optic network as an additional element to Universal fastening unit UK-N/U with 150mm offset (on SV poles)", in cases where it is necessary to install an optical box on a pole.
Provides the offset of the optical box from the pole at an offset of 150 mm.
Installation:
Fix the unit to the pole with a mounting tape (1 pc.)
Parameters:
Height – 565 mm
Material: steel strip 25*4
Provides the offset of the optical box from the pole at an offset of 150 mm.
Installation:
Fix the unit to the pole with a mounting tape (1 pc.)
Parameters:
Height – 565 mm
Material: steel strip 25*4
KUB-1 support
It is used in the construction of trunk and subscriber fiber optic network on the poles as a loop fastening for vertical and horizontal cable installation between the poles.
Installation: The unit is attached to the pole by means of a mounting tape (1 pc.).
Loops are fastened to the unit with binding bands or nylon clamps (ties).
Parameters:
Height 40 mm
Width 40 mm
Material: Made of 40*20 profile pipe
Installation: The unit is attached to the pole by means of a mounting tape (1 pc.).
Loops are fastened to the unit with binding bands or nylon clamps (ties).
Parameters:
Height 40 mm
Width 40 mm
Material: Made of 40*20 profile pipe
Light-1 support for fastening flat couplings to poles
Light-1 support for fastening flat couplings to poles.
Used during construction of trunk and subscriber optical fiber lines as a support for optical distribution box of SNR-FTTH-FDB-24A. type.
This support allows cable stock in d350 mm coil to be placed between the support and the pole.
Installation: The support is attached to the pole by means of a mounting tape (2 pcs.).
The optical distribution box is mounted using 3 M5 screws and M5 nuts (3 pcs.).
Cable stock:
Cable d10mm – 2 pcs. 5 m each
Cable d6mm – 8 pcs. 1.5 m each
Parameters:
Height 350 mm
Width 300 mm
Depth 80 mm
Used during construction of trunk and subscriber optical fiber lines as a support for optical distribution box of SNR-FTTH-FDB-24A. type.
This support allows cable stock in d350 mm coil to be placed between the support and the pole.
Installation: The support is attached to the pole by means of a mounting tape (2 pcs.).
The optical distribution box is mounted using 3 M5 screws and M5 nuts (3 pcs.).
Cable stock:
Cable d10mm – 2 pcs. 5 m each
Cable d6mm – 8 pcs. 1.5 m each
Parameters:
Height 350 mm
Width 300 mm
Depth 80 mm
Loop Support Sling
Used during construction on the trunk FOCL poles as a supplemental fastening.
This fastening is sliding, which allows to significantly accelerate the installation of cable lines. This fastening is multi-purpose and does not depend on cable diameter.
Installation: Shackle bolt No. 12 is required for installation.
Parameters: Sling – 25*360 Working load – 1kN.
This fastening is sliding, which allows to significantly accelerate the installation of cable lines. This fastening is multi-purpose and does not depend on cable diameter.
Installation: Shackle bolt No. 12 is required for installation.
Parameters: Sling – 25*360 Working load – 1kN.
Вернуться назад
FTTH optical subscriber outdoor cable 1SM
It is intended for laying through the poles and on the buildings, as well as for laying indoors, in attics, in pipes, cable trays.
It is used in FTTH networks for suspension on poles when connecting subscribers. FTTH cable SM1-F8 (FRP1.0) - with an extended power element.
Two 0.5 mm diameter FRP power elements and additional 1.8 mm diameter FRP power element make the cable resistant to tensile loading.
The outer coating is made of non-burning LSZH compound, UV resistant. The cable is fully dielectric.
It is used in FTTH networks for suspension on poles when connecting subscribers. FTTH cable SM1-F8 (FRP1.0) - with an extended power element.
Two 0.5 mm diameter FRP power elements and additional 1.8 mm diameter FRP power element make the cable resistant to tensile loading.
The outer coating is made of non-burning LSZH compound, UV resistant. The cable is fully dielectric.
FTTH reinforced cable
(FRP 1.8mm) 1SM
(FRP 1.8mm) 1SM
It is intended for laying through the poles and on the buildings, as well as for laying indoors, in attics, in pipes, cable trays.
It is widely used in the construction of PON and subscriber connections.
Fiber Optic cable FTTx SM1 UFN-01-F8 (FRP1.8) – LSZH- with an extended power element.
Two 0.5 mm diameter FRP power elements and additional 1.0 mm diameter FRP power element make the cable resistant to tensile loading.
The outer coating is made of non-burning LSZH compound, UV resistant.
The cable is fully dielectric.
It is widely used in the construction of PON and subscriber connections.
Fiber Optic cable FTTx SM1 UFN-01-F8 (FRP1.8) – LSZH- with an extended power element.
Two 0.5 mm diameter FRP power elements and additional 1.0 mm diameter FRP power element make the cable resistant to tensile loading.
The outer coating is made of non-burning LSZH compound, UV resistant.
The cable is fully dielectric.
FTTH patch cord
subscriber indoor
subscriber indoor
Designed for indoor laying in pipes, cable trays. It is used for the construction of subscriber connection networks in apartment buildings.
Fiber optic FTTH cable SM1 UFN-01-F-LSZH-W for indoor.
Two 0.5 mm diameter FRP power elements make the cable resistant to tensile loading.
The outer coating is made of non-burning LSZH compound, UV resistant. The cable is fully dielectric.
Fiber optic FTTH cable SM1 UFN-01-F-LSZH-W for indoor.
Two 0.5 mm diameter FRP power elements make the cable resistant to tensile loading.
The outer coating is made of non-burning LSZH compound, UV resistant. The cable is fully dielectric.
Вернуться назад
Backpack
Tailored to service provider engineers.
Color: grey.
Dimensions: 32x46x20 cm
Material: Polyester 1680D.
Color: grey.
Dimensions: 32x46x20 cm
Material: Polyester 1680D.
Organizer
Tailored to service provider engineers.
Color: Grey;
Dimensions: 30х30х4 cm
Material: Polyester 1680D.
Organizer can insert: connector crimping tool, wire cutters, adhesive tape, ties, hammer, pliers.
Color: Grey;
Dimensions: 30х30х4 cm
Material: Polyester 1680D.
Organizer can insert: connector crimping tool, wire cutters, adhesive tape, ties, hammer, pliers.
Вернуться назад
Roll-out unit for cable d400
Stand for rolling out fiber SM cable d400.
Designed for rolling out optical cable from the coil.
Material: Metal.
Ø50 cm (1 km coil).
Designed for rolling out optical cable from the coil.
Material: Metal.
Ø50 cm (1 km coil).
Roll-out unit for patch cord d370
Subscriber patch cord modular roll-out unit d370.
Designed for rolling out optical patch cords.
Material: Metal.
It should be installed on a hard surface.
Designed for rolling out optical patch cords.
Material: Metal.
It should be installed on a hard surface.
Stand for roll-out unit
Cable roll-out unit for patch cords (115x370 plug).
It is used for coils with dimensions of 290x107mm.
Material: Metal.
Designed for installation in the ground.
It is used for coils with dimensions of 290x107mm.
Material: Metal.
Designed for installation in the ground.
